The Featured Bus for August/September 2020 is Bus 490 – a Yutong ZK6131HG1 / E12
Bus 490 was a Yutong ZK6131HG1 “E12” battery electric bus which operated in Canberra between March 2020 and January 2021.
Canberra-based company Electromotiv leased the bus and charging equipment to Transport Canberra for a 12 month trial, with the option to extend the lease or buy outright.
The Yutong bus as supplied was built in Zhengzhou, China. It seated 40 with standing capacity of 17. Its battery capacity is 374kWh using four Lithium-ion battery packs and it reportedly has a maximum range of 400km on a full charge, although the bus configuration can be modified to add or remove battery packs.
Bus 490 was withdrawn from service in January 2021. In July 2023, this bus commenced operating for Punchbowl Bus Company.
Specifications:
| Length: | 12,170mm |
| Width: | 2,500mm |
| Height: | 3,420mm |
| Wheel Base: | 6,000mm |
| Overhang Front/Rear: | 2,740mm/3,430mm |
| Track Front/Rear: | 2,105mm/1,838mm |
| Gross Vehicle Mass (max permissible): | 18,000kg |
| Engine Arrangement | Single Rear mounted |
| Drive Motor Model | YTM280-CV9-H |
| Rated Output: | 215Kw continuous 350kw peak |
| Rated Torque: | 1200Nm |
| Battery Capacity: | 374Kwh |
More Images:
Further details:
- Bus 490 on ACT Bus Fleetwiki
- Media Release – “Electric bus to join Transport Canberra fleet” (ACT Government, 11 Nov 2019)
